Details
Ultrasonic hemostatic scalpel
OD (mm) |
ID (mm) |
Thickness (mm) |
Material |
Ceramic density (g/cm3) |
Capacitance (pF) |
Piezoelectric coefficient D33 (pC/N) |
Dielectric loss |
16 |
6 |
2.54 |
P8M |
>7.8 |
750-790 |
330±15 |
<0.2% |
16 |
6 |
2.54 |
P81 |
>7.7 |
640-680 |
300±15 |
<0.2% |
15 |
7 |
3 |
P8M |
>7.8 |
500-540 |
290±15 |
<0.2% |
8 |
4.2 |
2.4 |
P8M |
>7.8 |
150-180 |
290±15 |
<0.2% |
Ultrasonic bone scalpel / dental scaler
OD (mm) |
ID (mm) |
Thickness (mm) |
Material |
Ceramic density (g/cm3) |
Capacitance (pF) |
Piezoelectric coefficient D33 (pC/N) |
Dielectric loss |
15 |
6 |
2.54 |
P81 |
>7.7 |
750-790 |
330±15 |
<0.2% |
10 |
5 |
2 |
P81 |
>7.7 |
240-290 |
280±15 |
<0.2% |
Ultrasonic aspirator
OD (mm) |
ID (mm) |
Thickness (mm) |
Material |
Ceramic density (g/cm3) |
Capacitance (pF) |
Piezoelectric coefficient D33 (pC/N) |
Dielectric loss |
15 |
6 |
2.54 |
P81 |
>7.7 |
550-590 |
290±15 |
<0.2% |
Ultrasonic phaco tip
OD (mm) |
ID (mm) |
Thickness (mm) |
Material |
Ceramic density (g/cm3) |
Capacitance (pF) |
Piezoelectric coefficient D33 (pC/N) |
Dielectric loss |
9.5 |
5 |
2 |
P81 |
>7.7 |
240-290 |
280±15 |
<0.2% |
9.5 |
4.95 |
3.6 |
P8M |
>7.8 |
160-210 |
280±15 |
<0.2% |
